Slidetrack Blinds

Our Products

Pelmet / Headboxing

Durable aluminium pelmet system.

Channel and Side Tracks

Adjustable blind track system.

Wide range of fabrics

Versatile textile collection

Premium Motor Systems

Smart motorized shutter systems.

Why Choose Slidetrack Blinds?

At Dynamic Outdoors, we specialize in manufacturing high-quality outdoor blinds. We take pride in our attention to detail and use premium materials to create blinds that are not only aesthetically pleasing but also durable and long-lasting.

Slidetrack is an all Australian made product made especially for strong wind coastal areas. With a huge maximum width of 6.5m, it’s one of the largest single span blinds on the market. With mostly all metal parts and a heavy-duty bottom bar as standard, this blind is built tough!

Key Benefits of Our Aluminium Roller Shutters:

Large range of mesh options available
Manual, 240v and 12v operating options
Full range of powder coating colours

Learn More

RESIDENTIAL BLIND PROJECTS

BLINDS MANUFACTURED

Our Products

Pelmet / Headboxing

145mm Extruded Aluminium Head Box:

Unique two-piece pelmet produced with extruded aluminium and finished with specialized end caps
Fully enclosed head box offers a smooth shape for an attractive finish
Industry-leading strength due to the design and material thickness
Tested on blinds as wide as 6600mm, making it ideal for wide spans
Powder Coating: Available in special colors for customization

Channel and Side Tracks

Standard Channel:

The most commonly used channel, at 23mm deep, you simply fix the channel to the application surface & sit tracks in place. Each channel has +/- 5mm built-in adjustment. When happy with the blind’s operation, fix track to channel. If surface is square and measured correctly, there should be 5mm of channel visible when looking at the front of the blind.
Deep Channel:

Deep channels are 10mm deeper than standard. Installation method is exactly the same – this channel is simply an option to use for neatly overcoming protruding bricks or copper piping.
Extra Deep Channel:

21mm deeper than standard. Excessive out of square can be accommodated by using a STD channel half height, with a DEEP or EXTRA DEEP for the rest of the height.

Angled Channel:

For fixing to angled surfaces. Measure using the fabric as your line to the wall (dotted centre line in diagram). Drill a pilot, then a 13mmdiameter hole in the flat tube for your driver to fit through. Mount to wall. Place the curved channel over the top, (covering the 13mm holes.) Adjust to required angle and fix to flat tube with rivets or size 10-16x16mm tek screws.

Curved Channel:

For fixing to columns smaller than 200mm.For larger diameter columns a standard channel can be used. Simply fix to column, taking care not to over-tighten, as this may bend the channel edges out of shape.
